MI-DCZRM Morley Non-Addressable Zone Monitor Module

Add to Wishlist
Morley
> > SKU: MI-DCZRM
  • Connection of a zone of non-addressable detectors to an analogue addressable fire system
  • Built in isolation allowing system installation in stages without loss of protection
  • Monitors open circuit and short circuit faults
  • TRI-Colour Status LED
  • Zone powered from addressable loop wiring or external 24V PSU
  • Remote reset of non-addressable zone
  • Monitoring of external power supply
  • External fault input
  • CPD approval to EN54-17 and EN54-18, LPCB and VdS
  • DIN rail mountable, consistent with all other modules
  • Support for an extended power supply range as low as 18Vdc 60mA with an External PSU

$92.60 + VAT

Add to Quote
Compare

Description

Morley MI-DCZRM Non-Addressable Zone Monitor Module

The MI-DCZRM addressable zone monitor module allows a zone of non-addressable devices to communicate with a Morley-IAS protocol analogue addressable system. As a result, existing non-addressable zones can be integrated into a Morley-IAS protocol system. The module monitors a zone of two-wire non-addressable devices.

Each MI-DCZRM uses one of 99 available module addresses on a loop. A fault signal will be transmitted to the panel in case of an open circuit or short circuit on the non-addressable zone wiring or when the external fault input is pulled low (can be used for power supply monitoring). A flashing LED indicates that the module is in communication with the control panel. The LED latches steady on alarm (subject to current limitations).
